Type

2-way-passive enclosure

Powering and driving system

LA4X, LA8, LA12X

Bandwidth

27 Hz ([SYVA SUB_100] preset)

Maximum SPL

128 dB ([SYVA SUB_100] preset)

Nominal directivity

Standard Setting

Transducers

1 x 12”

Rigging

DIN580 - compatible M8 threaded insert for secondary safety

2 integrated inserts for rigging accessory

Dimension(W×H×D)

334 x 849 x 350 mm

13.1 x 33.4 x 13.8 in

Net weight

27 kg / 60 lb
